96W Dimmable LED Power Supply - Pool Rated UL 379
96W Dimmable LED Power Supply - Pool Rated UL 379
In-Stock (40) - Ships Same or Next Business Day
Description
The 96W Dimmable LED Power Supply is UL 379 rated for use in pool lighting applications and other bodies of water occupied by people. Designed for professional outdoor LED lighting systems, this versatile 5-in-1 power supply delivers reliable performance with flexible dimming options for a variety of installations. A durable steel housing provides resistance to rust and corrosion in damp and wet environments, while integrated mounting tabs allow for secure vertical installation, including exterior mounting with a junction box. Flicker-free dimming down to 1% provides precise control over light levels, and compatibility with Forward Phase (MLV), Reverse Phase (ELV), 0–10V, 0–10V PWM, and Potentiometer dimming makes it easy to integrate into a wide range of lighting systems.
Key Features
Key Features
-
5-Way Universal Dimming
-
UL 379 Rated
-
Mounting Tabs
-
Class 2 Rated
Specifications
Specifications
| Part # | AL-PS-N-96-24-P |
| Physical | |
| Dimensions | 8.72" long 4.6" wide 2" high |
| Housing Material | Steel |
| Mounting Method | Mounting Tabs |
| Weight | 3.95 lbs (1.79 kg) |
| Electrical | |
| AC Current | 1.3A |
| DC Voltage | 24VDC |
| Efficiency | Up to 88% |
| Frequency Range | 50 / 60Hz |
| Input Voltage | 120VAC |
| Inrush Current | 37.4A, 170us @50%Ipeak 120VA |
| Max Continuous Load | 76.8W |
| Max Output Current | 4A |
| Minimum Load | 10W |
| Output Power | 96W |
| Environmental | |
| Max Operating Temperature | -13°F to 113°F (-25°C to 45°C) |
| Max Storage Temperatures | -40°F to 176°F (-40°C to 80°C) |
| Suitable Uses | Dry, Damp and Wet Locations |
| Control | |
| Dimmable | Yes |
| Dimming Type | ELV MLV Triac 0-10V Potentiometer |
| Standards / Certifications | |
| Standards / Certifications | UL FCC Class 2 RoHS SELV Type HL |
| Warranty | 5 years |
Features
Features
Applications
Applications
Technical Documents
Technical Documents
FAQ
FAQ
Have a question and don't see the answer below? Chat live with an LED Expert
What does UL 379 certification mean?
Having a UL 379 certification means that this power supply has met the safety requirements associated with underwater lighting applications where people may be present. Pools and other bodies of water intended for people require a higher level of safety than unoccupied water features.
What dimming methods does this power supply support?
This power supply is 5-in-1, meaning it can support Forward Phase (MLV), Reverse Phase (ELV), 0–10V, 0–10V PWM, and Potentiometer dimming.
Where can this power supply be used?
This power supply is rated for dry, damp, and wet locations when installed in a junction box, making it suitable for both indoor and outdoor use. It's well suited for applications such as pools, hot tubs, and water fountains. See the Applications tab for additional location ideas.
