Spectra™ AllSun - LED Light Sheet - Ultrabright Tunable White
Spectra™ AllSun - LED Light Sheet - Ultrabright Tunable White
Regular price
$124.86
Sale price
$124.86
Regular price
$177.89
In-Stock (42) - Ships Same or Next Business Day
Description
aspectLED's dynamic White Color Tuning Flexible LED Light Sheets are the perfect solution for a wide variety of lighting applications including; retail signage, back-lighting, and other decorative lighting for holidays, trade shows, and exhibitions. These versatile color tuning flexible LED light sheets can be cut in any direction along the cut lines, allowing you to cut pieces to the length or shape that you need. **According to the National Electrical Code (NEC), wiring exceeding 96 watts is no longer considered Class 2 wiring.
Key Features
Key Features
-
12,000 Lumens
-
120 Watts
-
Voltage: 24VDC
-
Cuttable
Specifications
Specifications
| Part # | AL-LS-WWDW-U |
| Physical | |
| Adhesive Backing | Yes / 3M Adhesive |
| Cut Length | 0.78"x 0.78"(19.8mm x 19.8mm) |
| Dimensions | 18-15/16" (480mm) long x 9-1/2" (240mm) wide x 1/4" (6mm) thick |
| Estimated Lifespan | 50,000 hours |
| Electrical | |
| Input Voltage | 24VDC, Requires Power Supply |
| LED Quantity | 576 LEDs per sheet |
| Max Power Consumption | 120 Watts per sheet |
| Max Run Length | Maximum Run Length Maximum Run Length = 2. Both connectors must be used. Note that controllers do have an electrical current limit. Running multiple sheets may exceed the current limit depending on which controller is used. |
| Photometric | |
| CRI | >95 |
| LED Color Options | 3000K-6000K |
| Max Lumens | 12,000 Lumens per sheet |
| Environmental | |
| IP Rating | IP20 Indoor Use Dry Location |
| Suitable Uses | Dry Location Only |
| Control | |
| Dimmable | Yes |
| Standards / Certifications | |
| Standards / Certifications | RoHS, UL Listed |
| Warranty | 1 Year |
Features
Features
Applications
Applications
Technical Documents
Technical Documents
FAQ
FAQ
Have a question and don't see the answer below? Chat live with an LED Expert
