In-Wall Touch Panel Controller DMX + RF for RGBCCT Lights
In-Wall Touch Panel Controller DMX + RF for RGBCCT Lights
In-Stock (113) - Ships Same or Next Business Day
Description
Effortlessly control your RGBCCT LED lighting with this sleek, in-wall mounted controller. Featuring a modern glass touch interface, it allows for precise adjustments to both color temperature and brightness, delivering smooth, independent dimming from 1–100% along with full RGBCCT tuning.
Designed for versatility, this controller is compatible with universal DMX decoders and can operate via a hardwired DMX connection or wirelessly through RF receivers, giving you flexible installation options. Compatible with both 12VDC and 24VDC systems, it’s an ideal solution for dynamic lighting applications.
Key Features
Key Features
-
5 Channel
-
Input Voltage
12VDC or 24VDC -
Wireless
Specifications
Specifications
| Part # | AL-CTLR-RGBCCT-1ZRF-DMX-WMT |
| Physical | |
| Dimensions | 2.95" long (75mm) 4.72" wide (120mm) 1.15" high (29.1mm) |
| Mounting Method | Wall Mount |
| Weight | 7.76oz (0.22kg) |
| Electrical | |
| Input Voltage | 12-24VDC |
| Environmental | |
| IP Rating | IP20 |
| Max Operating Temperature | 32-104° F (0-40° C) |
| Max Storage Temperatures | 32-104°F (0-40°C) |
| Suitable Uses | Indoor Dry Locations |
| Standards / Certifications | |
| Standards / Certifications | FCC, RoHS, CE |
| Warranty | 5 Years |
Features
Features
Applications
Applications
Technical Documents
Technical Documents
FAQ
FAQ
Have a question and don't see the answer below? Chat live with an LED Expert
