InDrive 2-in-1 Dimmer Switch + Driver, 96W - CCT
InDrive 2-in-1 Dimmer Switch + Driver, 96W - CCT
Description
Compact, versatile, and efficient, this all-in-one dimmer and driver eliminates the need for a separate power supply. Adjust the color temperature and brightness effortlessly to suit any task, from warm ambient lighting to bright task lighting. Compatible with single-pole and 3-way configurations, it dims smoothly down to 3% brightness. Streamline installation, reduce labor costs, and simplify your lighting setup. With precise CCT color tuning, choosing the right color temperature is simple, and compatible drivers are automatically handled.
Key Features
Key Features
-
2-in-1 (Integrated Power)
-
120VAC Input
-
Flicker Free
-
Multi-location Control
Dimensions
Dimensions
Specifications
Specifications
| Part # | AL-TRK-DIMDRV-CCT |
| Physical | |
| Dimensions | 36 mm Deep (1.42"), 32.5 mm Wide (1.28"), 66 mm Tall (2.6") |
| Mounting Method | In-Wall Switch Box |
| Pole Type | Single or 3-pole |
| Weight | 9.38 oz (0.25 kg) |
| Electrical | |
| Input Voltage | 120 VAC |
| Max Power Consumption | 96 W |
| Output Signal | 16 kHz PWM Output |
| Environmental | |
| IP Rating | IP65 |
| Suitable Uses | Indoor, Dry, Damp locations |
| Compatibility | |
| Compatible Power Supplies | N/A — Power supply built in |
| Standards / Certifications | |
| Standards / Certifications | ROHS UL Listed FCC Class 2 Class P SELV REACH |
| Warranty | 3 year warranty |
Features
Features
Applications
Applications
Technical Documents
Technical Documents
FAQ
FAQ
Have a question and don't see the answer below? Chat live with an LED Expert
