Wireless RGBCCT 5 Channel LED Controller
Wireless RGBCCT 5 Channel LED Controller
In-Stock (320) - Ships Same or Next Business Day
Description
The Wireless RGBCCT 5 Channel LED Controller provides flexible, reliable control for color-changing LED lighting systems. Designed for 12–24VDC installations, this controller supports single color, tunable white, RGB, RGBW, and RGBCCT fixtures with five independent output channels. Using RF wireless communication, it allows responsive control from compatible remotes without requiring line-of-sight. The built-in receiver and repeater functionality helps extend signal range, making it easy to expand lighting control across larger installations. With PWM dimming technology, the controller delivers smooth brightness adjustments, seamless color transitions, and dynamic lighting effects. Its compact, surface-mount design allows for straightforward installation in residential, commercial, and entertainment lighting applications.
Key Features
Key Features
-
5 Channel
-
RF
-
Input Voltage
12VDC or 24VDC -
Dimming & Effects
Specifications
Specifications
| Part # | AL-CTLR-RGBCCT-5CP |
| Physical | |
| Dimensions | 6.7" long (170mm) x 2.32" wide (59mm) x 1.14" high (29mm) |
| Housing Color | White |
| Mounting Method | Surface Mount |
| Weight | 0.4 |
| Electrical | |
| Input Voltage | 12-48VDC |
| Inrush Current | Max. 8A/CH@12V/24V When a power source is over 60W at 12VDC/96W at 24VDC it is no longer classified as a Class 2 circuit per the NEC. |
| Output Power | Max. 96W/CH@12V Max. 192W/CH@24V |
| Environmental | |
| IP Rating | IP20 |
| Max Operating Temperature | -4 to 122° F (-20 to 50° C) |
| Max Storage Temperatures | -4 - 122° F (-20 - 50° C) |
| Suitable Uses | Indoor Dry Locations |
| Standards / Certifications | |
| Standards / Certifications | UL, RoHS, CE |
| Warranty | 5 Years |
Features
Features
Applications
Applications
Technical Documents
Technical Documents
FAQ
FAQ
Have a question and don't see the answer below? Chat live with an LED Expert
