Casambi 5 Channel PWM Controller
Casambi 5 Channel PWM Controller
In Stock (20) - Moving Fast!
Description
The Casambi 5 Channel PWM Controller is a Bluetooth dimmer designed for constant voltage LED strip lights, neon flex, and light sheet systems. Built for flexibility and ease of use, this 5 channel controller supports static white, tunable white, RGB, RGBW, and RGBCCT color systems. Casambi’s Bluetooth mesh technology allows users to control up to 250 devices within a single network, making it one of the most scalable wireless lighting control systems available.
As a Class 2 device, the PWM 4 supports a maximum load of 96W at 24V or 48W at 12V. Control and configuration are handled through the Casambi mobile app, available on both iOS and Android.
Key Features
Key Features
-
App Control
-
Wireless
-
RGBCCT Compatible
-
Bluetooth
Specifications
Specifications
| Part # | AL-CTLR-CBU-PWM5PRO |
| Physical | |
| Dimensions | 3.94" (100mm) x 1.85" (47mm) x 0.89" (22mm) |
| Mounting Method | Surface Mount |
| Weight | 0.1 lb |
| Electrical | |
| Input Voltage | 12-24VDC |
| Inrush Current | 12VDC=5A 24VDC=4.16A |
| Output Power | 12VDC=5A 24VDC=4.16A |
| Environmental | |
| IP Rating | IP20 |
| Max Operating Temperature | -4 to 122° F (-20 to 50° C) |
| Max Storage Temperatures | -4 - 122°F (-20 - 50°C) |
| Suitable Uses | Indoor Dry Locations |
| Standards / Certifications | |
| Standards / Certifications | UL, FCC |
| Warranty | 1 year |
Features
Features
Technical Documents
Technical Documents
FAQ
FAQ
Have a question and don't see the answer below? Chat live with an LED Expert
